Louvre Window | H2205 x W600

The H2205 x W600 aluminium louvre window is a tall, floor-to-ceiling vertical window designed to deliver full-height airflow, precise ventilation control, and clean architectural lines for Australian homes. Measuring 2205mm high by 600mm wide, this narrow profile is ideal for modern breezeways, stairwells, and flanking large fixed picture windows or entryway doors. Built with a heavy-duty extruded aluminium frame and smooth blade galleries, it allows homeowners and builders to capture cool breezes from floor to ceiling while maintaining dependable weatherproofing and ground-floor security.

Key Features & Technical Specifications

• Dimensions: Exactly 2205mm in height and 600mm in width, offering a generous vertical span that creates a dramatic floor-to-ceiling architectural feature.

• Frame Profile & Strength: Engineered from commercial-grade extruded aluminium that resists warping, corrosion, and structural deflection across tall 2205mm vertical spans.

• Glass & Blade Options: Configurable with multiple 102mm or 152mm glass blades including Clear, Grey Tint, Low-E thermal glass, Satinlite Obscure for privacy, and double-glazed variants.

• Colour Palette: Choose from durable architectural powder-coated finishes including Pearl White, Custom Black, or specify a Custom Colour to match your facade palette.

• Screen & Security Compatibility: Fully adaptable frame structure that accommodates No Screens, standard Flyscreens, Diamond Grille, or high-tensile Stainless Steel Security Screens.

• Hardware & Locking Mechanism: Equipped with heavy-duty mechanical blade galleries and integrated key-lockable handles that clamp the glass blades tightly together when closed.

• Weather & Energy Performance: Engineered with dual-seal weather stripping around the frame perimeter for dependable protection against wind and driving rain, helping your home achieve optimal WERS compliance.

Ideal Applications for Australian Homes

A 2205mm tall louvre window is a practical design tool for architects, builders, and homeowners who want to maximize natural ventilation across two-storey voids, tall entryways, and contemporary open-plan living areas. Because warm air naturally rises, installing a floor-to-ceiling louvre window in a stairwell or double-height hallway lets you purge trapped summer heat from the upper levels of your home quickly and efficiently.

In modern residential builds, this narrow 600mm profile is frequently used as a ventilation flanker next to a wide picture window or a solid timber entry door. You get the aesthetic benefit of a full-height glass wall alongside adjustable airflow that you can regulate throughout the day. For coastal properties across Sydney and regional New South Wales, the marine-grade aluminium construction withstands salty sea air while drawing cool ocean breezes right through the house.

Configuration Guidance: Customising Your Window

When ordering your H2205 x W600 louvre window online, step through our custom configuration options to suit your room layout and practical requirements:

1. Selecting Your Colour: Pearl White works beautifully on coastal builds and classic brick homes, reflecting harsh summer heat. Custom Black creates a bold industrial outline that pairs well with polished concrete floors and timber cladding. If your project requires an exact match to existing steelwork, our Custom Colour service ensures an accurate finish.

2. Choosing Your Glass: Because a 2205mm window spans from near floor level up to the ceiling, privacy and thermal performance are essential. For street-facing rooms or ground-floor bathrooms, Satinlite Obscure glass lets daylight pour in while completely obscuring outside visibility. If the window faces west and receives intense afternoon sun, Low-E glass or Grey Tint cuts solar heat gain and protects interior timber flooring from UV fading.

3. Picking the Right Screen: Tall window openings can let in unwanted insects if left unshielded during summer evenings. Standard flyscreens provide dependable everyday bug deterrence. For ground-floor installations where security is a priority, upgrading to a Stainless Steel Security Screen lets you leave your louvre blades tilted open for overnight cooling while keeping a physical barrier against intruders.

Australian Standards, Engineering & Quality Guarantee

Every H2205 x W600 louvre window from New Age Construction Group is manufactured to comply with AS 2047, the mandatory Australian Standard for windows and external glazed doors. Tall vertical blades require exact gallery alignment to prevent rattling and wind deflection, which is why our frames undergo rigorous physical testing for structural strength, air infiltration, and water penetration resistance.

Manufactured at our Smeaton Grange facility in New South Wales, our windows are built using commercial-grade aluminium and quality hardware designed for Australian weather conditions. Whether you are a trade professional ordering for a residential development or a homeowner managing a major extension, our windows arrive fully assembled and ready for installation. Standard lead times run between 12 to 15 working days to accommodate custom powder coating, precision blade cutting, and quality control prior to Australia-wide dispatch.

Frequently Asked Questions

Why choose a 2205mm tall louvre window? A 2205mm tall louvre window provides full-height vertical ventilation from floor to ceiling. It is ideal for purging hot air from stairwells, creating breezeways in open-plan living rooms, and flanking entry doors or picture windows with adjustable airflow.

Can I clean the outside glass blades from inside the house? Yes. One of the major practical advantages of a louvre window is that you can tilt the blades to an open horizontal angle and easily wipe both the interior and exterior glass surfaces from inside your home. This makes cleaning tall upper-floor windows safe and straightforward.

What is the standard manufacturing lead time for custom louvre windows? Custom aluminium windows from New Age Construction Group typically require a manufacturing lead time of 12 to 15 working days. This allows sufficient time for custom powder coating, glass sizing, and thorough quality inspection before shipping anywhere in Australia.
