Louvre / Louvre Window| H2205 x W1800

The H2205 x W1800 double-bay aluminium louvre window is a grand floor-to-ceiling architectural window engineered to transform residential facades and indoor-outdoor living spaces. Measuring 2205mm high by 1800mm wide, this expansive profile features two side-by-side louvre bays (Louvre / Louvre) set within a single reinforced commercial aluminium outer frame. This dual-gallery design gives Australian homeowners complete ventilation control across a massive 1.8-metre opening, delivering unobstructed natural light, high-volume cross-ventilation, and dependable weatherproofing without compromising structural integrity.

Key Features & Technical Specifications

• Dimensions & Bay Layout: Exactly 2205mm in height and 1800mm in width, configured as a double-bay louvre window with two independent operating banks of horizontal glass blades.

• Frame Profile & Strength: Built from heavy-duty commercial extruded aluminium, engineered with a reinforced central structural mullion to prevent frame deflection, sagging, and blade rattling across large floor-to-ceiling spans.

• Glass & Blade Options: Configurable with 102mm or 152mm glass blades in Clear, Grey Tint, Low-E thermal glass, Satinlite Obscure for privacy, and double-glazed variants for superior climate insulation.

• Colour Palette: Choose from hard-wearing architectural powder-coated finishes including Pearl White, Custom Black, or specify a Custom Colour to match your exterior brickwork, cladding, and roofing scheme.

• Screen & Security Compatibility: Features an integrated external screen recess that accepts No Screens, standard Flyscreens, Diamond Grille, or heavy-duty Stainless Steel Security Screens across both louvre bays.

• Hardware & Locking Mechanism: Equipped with dual mechanical blade galleries and key-lockable operating handles, allowing you to operate each bay independently and clamp the glass blades shut securely.

• Weather & Energy Performance: Built with perimeter dual-seal weather stripping and interlocking blade closure to stop air draughts and driving rain, helping your property achieve strong WERS compliance.

Ideal Applications for Australian Homes

A 2205mm high by 1800mm wide double-bay louvre is essentially the size of a large double door opening, making it one of the most effective primary architectural windows in residential construction. Because it spans from near floor level up to standard ceiling height across an expansive 1.8-metre width, architects and builders frequently specify this window for main living rooms, open-plan dining zones, and custom sunrooms.

Where a standard 1800mm sliding window only allows half of the glass area to slide open, a double-bay louvre window gives you 100 percent opening capacity across the entire frame. This massive opening area allows you to flush trapped summer heat out of your home in minutes. Having two separate louvre bays provides a major practical advantage for daily climate control. On windy coastal afternoons, you can leave the windward bay closed to protect indoor living areas while tilting the opposite bay open to draw fresh air inside. Because the glass blades rotate on a horizontal axis, you can direct airflow upward toward the ceiling to cool the room without creating floor-level draughts.

This tall architectural dimension also makes a striking visual feature in coastal homes across Sydney, Newcastle, and regional New South Wales. The marine-grade aluminium frame handles salty sea air effortlessly while framing panoramic backyard or ocean views.

Configuration Guidance: Customising Your Window

When ordering your H2205 x W1800 double-bay louvre window online, step through our custom configuration options to match your room layout and environmental needs:

1. Selecting Your Colour: Pearl White remains a practical choice for coastal properties and classic weatherboard homes, reflecting intense summer sun. Custom Black creates a sharp modern industrial outline that pairs well with timber decking, matte black door hardware, and polished concrete floors. If your project requires an exact match to existing window frames or steelwork, our Custom Colour service ensures an accurate finish.

2. Choosing Your Glass: Because a 2205mm by 1800mm window presents an exceptionally large glass surface area, managing solar heat gain is vital. For north or west-facing living rooms, Low-E glass or Grey Tint reduces afternoon glare and cuts heat transfer while keeping interiors bright. If the window faces a boundary fence or neighbouring property, Satinlite Obscure glass lets daylight pour in while protecting your personal privacy.

3. Picking the Right Screen: Large floor-to-ceiling openings require dependable insect protection during warm Australian evenings. Standard flyscreens keep mosquitoes and flies out while you leave your double-bay louvres open for overnight cooling. For ground-floor installations where security is a top priority, upgrading to a Stainless Steel Security Screen lets you leave both bays tilted open safely while maintaining a reinforced steel barrier against intruders.

Australian Standards, Engineering & Quality Guarantee

Every H2205 x W1800 double-bay louvre window from New Age Construction Group is manufactured to comply with AS 2047, the mandatory Australian Standard for windows and external glazed doors. Combining an 1800mm width with a 2205mm vertical span requires exact gallery alignment and robust central mullion support to prevent blade rattling and wind deflection. This is why our frames undergo strict physical testing for structural deflection, operating force, air infiltration, and water penetration resistance.

Manufactured at our Smeaton Grange facility in New South Wales, our windows are built using commercial-grade aluminium and quality hardware engineered for Australian weather conditions. Whether you are a trade builder ordering for a residential development or a homeowner managing a major extension, our windows arrive fully assembled and ready for installation. Standard lead times run between 12 to 15 working days to accommodate custom powder coating, precision blade cutting, and quality control prior to Australia-wide dispatch.

Frequently Asked Questions

Is an 1800mm wide by 2205mm tall louvre window safe in high wind areas? Yes. Our commercial-grade extruded aluminium frames and heavy-duty blade galleries are engineered with a reinforced central structural mullion to comply with AS 2047 standards for wind deflection and structural strength. When closed, the blades overlap and seal tightly against perimeter weather strips to resist high winds and heavy rain.

How do I operate a double bay louvre window of this size? The window is split into two independent vertical bays, each equipped with its own mechanical gallery and operating handle. You can open both bays fully for maximum cross-ventilation, or operate them independently to direct airflow exactly where you want it.

What is the standard manufacturing lead time for custom louvre windows? Custom aluminium windows from New Age Construction Group typically require a manufacturing lead time of 12 to 15 working days. This allows sufficient time for custom powder coating, glass sizing, and thorough quality inspection before shipping anywhere in Australia.

Order Your Custom Louvre Window Today

Upgrade your home with a stunning floor-to-ceiling architectural feature window. Configure your H2205 x W1800 double-bay aluminium louvre window above by choosing your frame colour, glass type, and screen option, or contact our Smeaton Grange team for a custom trade quote today.
